| POWERPOINT |
| PRESSURE GAUGE |
| SIZE | PRESSURE RANGE | THREAD |
| 1.5"-40 mm | 30 to 1000 Psi | 1/8" BSP |
| 1.5"-40 mm | Back Connection 30 to 1000 Psi | 1/8" BSP |
| 1.5"-40 mm | Back Connection Penal Mounting(B.C.P.M.) 30 to 1000 Psi | 1/8" BSP |
| 2.0"-50 mm | 30 to 1000 Psi | 1/8",1/4" BSP |
| 2.0"-50 mm | Oxygen 3000, 200 Psi | 1/4"BSP, 1/4" NPT |
| 2.0"-50 mm | Acetylene 600, 40 Psi | 1/4"BSP, 1/4"NPT |
| 2.0"-50 mm | Argon, Co, Nitrogen 0 to 4000 Psi | 1/4" BSP, 1/4"NPT |
| 2.0"-50 mm | LPG Gas 0 to 16 kg/cm² | 1/4" BSP |
| 2.0"-50 mm | C.N.G. Gas 0 to 280 kg/cm²(Back Con.) | 1/4"BSP |
| 2.0"-50 mm | Back Connection 30 to 1000 Psi | 1/8", 1/4" BSP |
| 2.0"-50 mm | Back Connection Penal Mounting (B.C.P.M) 30 1000 Psi | 1/8", 1/4" BSP |
| 2.0"-50 mm | Vacuum Gauge 0 to 30mm. Hg., 0 to 760in.Hg. | 1/8", 1/4" BSP |
| 2.0"-50 mm | Twin Type Air Check Connection 0-150 Psi | - |
| 2.0"-50 mm | Hose Pipe Air Check Connection 0-150 Psi | - |
| 2.0"-50 mm | Maruti Air Check Connection 0-150 Psi | - |
| 2.5"-63 mm | 30 to 1000 Psi | 1/8",1/4" BSP |
| 2.5"-63 mm | 1500 to 2000 Psi | 1/8", 1/4" BSP |
| 2.5"-63 mm | 3000 to 4000 Psi | 1/8", 1/4" BSP |
| 2.5"-63 mm | Back Connection 30 to 1000 Psi | 1/8", 1/4" BSP |
| 2.5"-63 mm | Back Connection Penal Mounting (B.C.P.M.) 30 to 1000 Psi | 1/8", 1/4" BSP |
| 2.5"-63 mm | Vaccum Gauge 0 to 30mm.Hg., 0 to 760in. Hg. | 1/8", 1/4" BSP |
| 2.5"-63 mm | Compound Gauge 30mm Hg. to 30, 50, 100, 150, 200, 300 Psi | 1/8", 1/4" BSP |
| 2.5"-63 mm | Twin Type Air Check Connection 0-150 Psi | - |
| 2.5"-63 mm | Hose Pipe Air Check Connection 0-150 Psi | - |
| 3.0"-75 mm | 30 to 1000 Psi | 3/8" BSP |
| 3.0"-75 mm | Vacuum Gauge 0 to 30mm. Hg., 0 to 760in.Hg. | 3/8" BSP |
| 3.0"-75 mm | Back Connection 30 to 1000 Psi | 3/8" BSP |
| 3.0"-75 mm | Back Connection Penal Mounting(B.C.P.M.) 30 1000 Psi | 3/8" BSP |
| 3.0"-75 mm | 0 to 380 Psi for SODA WATER MACHINE | 1/4", 3/8" BSP |
| 4.0"-100 mm | 30 to 1000 Psi | 3/8" BSP |
| 4.0"-100 mm | 1500, 2000, 2500 Psi | 3/8" BSP |
| 4.0"-100 mm | 3000, 4000 Psi & 1 Ton | 3/8" BSP |
| 4.0"-100 mm | 5000, 6000 Psi & 2 Ton | 3/8" BSP |
| 4.0"-100 mm | Back Connection 30 to 1000 Psi | 3/8" BSP |
| 4.0"-100 mm | Back Connection Panel Mounting(B.C.P.M) 30 to 1000 Psi | 3/8" BSP |
| 4.0"-100 mm | Vacuum Gauge 0 to 30mm.Hg., 0 to 760in.Hg. | 3/8" BSP |
| 4.0"-100 mm | Compound Gauge 30 mm. Hg. TO 30, 50, 100, 150, 200, 300 Psi | 3/8" BSP |
| 4.0"-100 mm | Feet & Metre of Water 0-100 to 0-1600 Feet | 3/8" BSP |
| 4.0"-100 mm | Tyre Air Checking Gauge 150, Psi, With 70cm Hose & Twin Connector | 3/8" BSP |
| SIZE | PRESSURE RANGE | THREAD |
| 6.0"-150 mm | 30 to 1000 Psi | 3/8" BSP |
| 6.0"-150 mm | Vacuum Gauge 0 to 30mm.Hg., 0 to 760in. Hg. | 3/8" BSP |
| 6.0"-150 mm | Feet & Metre Of water 0-100 to 0-1600 Feet | 3/8" BSP |
| 10.0"-250 mm | 50 to 1000 Psi | 3/8", 1/2" BSP |
| 10.0"-250 mm | Feet & Metre Of Water 0-100 to 0-1600 Feet | 3/8", 1/2" BSP |
| 10.0"-250 mm | Air Check Wall Mounted Gauge (with Alluminium casting Body) Three Way Connection |
- |
| 10.0"-250 mm | Air Check Wall Mounted Gauge (with Alluminium casting Body) Three Way Connection With Rubber Hose & Accessories |
- |
| SIZE | TEMPERATURE GAUGE | THREAD |
| 4.0"-100 mm | 0 to 100, 120, 150, 200, 250, 300°C Stamp Type (12" Long) | 1/2" BSP |
| 4.0"-100 mm | 0 to 400, 500, 600°C Stamp Type (12"Long) | 1/2" BSP |
| 4.0"-100 mm | 0 to 100, 120, 150, 200, 250, 300°C Capillary Type (3 mts. Length & PVC Covering) |
1/2" BSP |
| 4.0"-100 mm | 0 to 400, 500, 600°C Capillary Type (3 mts. Length & PVC Covering) |
1/2" BSP |
| 6.0"-150 mm | 0 to 100, 120, 150, 200, 250, 300°C Stamp Type(12"long) | 1/2" BSP |
| 6.0"-150 mm | 0 to 400, 500, 600°C Stamp Type (12" Long) | 1/2" BSP |
| 6.0"-150 mm | 0 to 100, 120, 150, 200, 250, 300°C Capillary Type (3 mts. Length & PVC Covering) |
1/2" BSP |
| 6.0"-150 mm | 0 to 400, 500, 600°C Capillary Type (3 mts. Length & PVC Covering) |
1/2" BSP |
 |
Size: 50mm(2 Inch)
Range: 0 to 60, 100, 150,200 Psi
Case: M.S Drawn, Protected with Soft Cover
Features: Heavy Duty Connector for Tyre Pressure Checking |
 |
Size: 50mm(2 Inch)
Range: 0 to 60, 100, 150,200 Psi
Case: M.S Drawn, Protected with Soft Cover
HOSE: 15 " Long PVC Heavy Duty
Features: There is no direct burden on gauge, therefore, life of the gauge will be more |
|
 |
Size: 63mm(2.5 Inch)
Range: 0 to 60, 100, 150,200 Psi
Case: M.S Drawn, Protected with Soft Cover
TTC: 7" Long TTC Heavy Duty
Features: Heavy Duty Connector for Tyre Pressure Checking |
 |
Size: 63mm(2.5 Inch)
Range: 0 to 60, 100, 150,200 Psi
Case: M.S Drawn, Protected with Soft Cover
HOSE: 18 " Long PVC Heavy Duty
Features: There is no direct burden on gauge, therefore, life of the gauge will be more |
|
 |
Size: 63mm(2.5 Inch)
Range: 0 to 60, 100, 150,200 Psi
Case: M.S Drawn, Protected with Soft Cover
HOSE: 18 " Long PVC Heavy Hose
TTC: 7" Long TTC with Air Chuck
Features: Heavy Duty Connector for Tyre Pressure Checking. There is no direct burden on gauge, therefore, life of the gauge will be more |
 |
Size: 63mm(2.5 Inch)
Range: 0 to 60, 100, 150,200 Psi
Case: M.S Drawn, Protected with Soft Cover
TTC: 10 " Long TTC with Heavy Air Chuck
Features: Heavy Duty Connector for Tyre Pressure Checking
|
|
 |
Size: 50mm(2 Inch)
Range: 0 to 60, 100, 150,200 Psi
Case: M.S Drawn, Protected with Soft Cover
TTC: 7" Long TTC Heavy Duty
Applications: Handy Gauge Suitable for Tractor, Scooter & Light Vehicle
|
 |
Size: 100mm(4 Inch)
Range: 0 to 150,200 Psi
Case: M.S Drawn Case & Bazel
Hose: 28" Long PVC Hose
TTC: 7" Long TTC with Air Check
Applications: Light & Heavy Vehicle
|
|
 |
Size: 250mm(10 Inch)
Range: 0 to 150, 200 Psi
Case: M.S Drawn Case & Bazel Covered with Red Protection Ring with Light Arrangement.
Applications:Petrol Pump & Service Station
|
 |
Size: 50mm(2 Inch)
Range: 60, 100, 150, 200, 250, 300, 500 Psi
Case: M.S Drawn Case & Bazel. Powder coting Mat finished color.
Material: Internal all Brass
Connection: 1/4, 1/8, B.S.P
Applications: Compressor, Twin & Hose Connection, for Air, Water, Oil, Steam.
|
|
 |
Size: 63 mm(2.5 Inch)
Range: 60, 100, 150, 200, 250, 300 Psi
Case: M.S Drawn Case & Bazel. Powder coting Mat finished color.
Material: Internal all Brass
Connection: 1/4, 1/8, B.S.P
Applications: Compressor, Twin & Hose Connection, for Air, Water, Oil, Steam.
|
 |
Two in One Air chuck for Cycle cum Scooter
Material: Glass fiber & Brass |
|
 |
Washer for Twin Type Connector |
|||
 |
Twin Tyre Connector suitable for 1/4" & 1/8" BSP Pressure Gauge. |
 |
Twin Tyre Connector suitable for 6 MM & 8 MM Hose Air Filling |
|
 |
